2.3. Big-O Notation

When trying to characterize an algorithm’s efficiency in terms of execution time, independent of any particular program or computer, it is important to quantify the number of operations or steps that the algorithm will require. If each of these steps is considered to be a basic unit of computation, then the execution time for an algorithm can be expressed as the number of steps required to solve the problem. Deciding on an appropriate basic unit of computation can be a complicated problem and will depend on how the algorithm is implemented.

A good basic unit of computation for comparing the summation algorithms shown earlier might be to count the number of assignment statements performed to compute the sum. In the function sumOfN, the number of assignment statements is 1 (\(theSum = 0\)) plus the value of n (the number of times we perform \(theSum=theSum+i\)). We can denote this by a function, call it T, where \(T(n)=1 + n\). The parameter n is often referred to as the “size of the problem,” and we can read this as “T(n) is the time it takes to solve a problem of size n, namely 1+n steps.”

In the summation functions given above, it makes sense to use the number of terms in the summation to denote the size of the problem. We can then say that the sum of the first 100,000 integers is a bigger instance of the summation problem than the sum of the first 1,000. Because of this, it might seem reasonable that the time required to solve the larger case would be greater than for the smaller case. Our goal then is to show how the algorithm’s execution time changes with respect to the size of the problem.

Computer scientists prefer to take this analysis technique one step further. It turns out that the exact number of operations is not as important as determining the most dominant part of the \(T(n)\) function. In other words, as the problem gets larger, some portion of the \(T(n)\) function tends to overpower the rest. This dominant term is what, in the end, is used for comparison. The order of magnitude function describes the part of \(T(n)\) that increases the fastest as the value of n increases. Order of magnitude is often called Big-O notation (for “order”) and written as \(O(f(n))\). It provides a useful approximation to the actual number of steps in the computation. The function \(f(n)\) provides a simple representation of the dominant part of the original \(T(n)\).

In the above example, \(T(n)=1+n\). As n gets large, the constant 1 will become less and less significant to the final result. If we are looking for an approximation for \(T(n)\), then we can drop the 1 and simply say that the running time is \(O(n)\). It is important to note that the 1 is certainly significant for \(T(n)\). However, as n gets large, our approximation will be just as accurate without it.

As another example, suppose that for some algorithm, the exact number of steps is \(T(n)=5n^{2}+27n+1005\). When n is small, say 1 or 2, the constant 1005 seems to be the dominant part of the function. However, as n gets larger, the \(n^{2}\) term becomes the most important. In fact, when n is really large, the other two terms become insignificant in the role that they play in determining the final result. Again, to approximate \(T(n)\) as n gets large, we can ignore the other terms and focus on \(5n^{2}\). In addition, the coefficient \(5\) becomes insignificant as n gets large. We would say then that the function \(T(n)\) has an order of magnitude \(f(n)=n^{2}\), or simply that it is \(O(n^{2})\).

Although we do not see this in the summation example, sometimes the performance of an algorithm depends on the exact values of the data rather than simply the size of the problem. For these kinds of algorithms we need to characterize their performance in terms of best case, worst case, or average case performance. The worst case performance refers to a particular data set where the algorithm performs especially poorly. Whereas a different data set for the exact same algorithm might have extraordinarily good performance. However, in most cases the algorithm performs somewhere in between these two extremes (average case). It is important for a computer scientist to understand these distinctions so they are not misled by one particular case.

A number of very common order of magnitude functions will come up over and over as you study algorithms. These are shown in Table 1. In order to decide which of these functions is the dominant part of any \(T(n)\) function, we must see how they compare with one another as n gets large.

Table 1: Common Functions for Big-O
f(n) Name
\(1\) Constant
\(\log n\) Logarithmic
\(n\) Linear
\(n\log n\) Log Linear
\(n^{2}\) Quadratic
\(n^{3}\) Cubic
\(2^{n}\) Exponential

Figure 1 shows graphs of the common functions from Table 1. Notice that when n is small, the functions are not very well defined with respect to one another. It is hard to tell which is dominant. However, as n grows, there is a definite relationship and it is easy to see how they compare with one another.

../_images/newplot.png

Figure 1: Plot of Common Big-O Functions

As a final example, suppose that we have the fragment of Python code shown in Listing 2. Although this program does not really do anything, it is instructive to see how we can take actual code and analyze performance.

Listing 2

a=5
b=6
c=10
for i in range(n):
   for j in range(n):
      x = i * i
      y = j * j
      z = i * j
for k in range(n):
   w = a*k + 45
   v = b*b
d = 33

The number of assignment operations is the sum of four terms. The first term is the constant 3, representing the three assignment statements at the start of the fragment. The second term is \(3n^{2}\), since there are three statements that are performed \(n^{2}\) times due to the nested iteration. The third term is \(2n\), two statements iterated n times. Finally, the fourth term is the constant 1, representing the final assignment statement. This gives us \(T(n)=3+3n^{2}+2n+1=3n^{2}+2n+4\). By looking at the exponents, we can easily see that the \(n^{2}\) term will be dominant and therefore this fragment of code is \(O(n^{2})\). Note that all of the other terms as well as the coefficient on the dominant term can be ignored as n grows larger.

../_images/newplot2.png

Figure 2: Comparing \(T(n)\) with Common Big-O Functions

Figure 2 shows a few of the common Big-O functions as they compare with the \(T(n)\) function discussed above. Note that \(T(n)\) is initially larger than the cubic function. However, as n grows, the cubic function quickly overtakes \(T(n)\). It is easy to see that \(T(n)\) then follows the quadratic function as \(n\) continues to grow.

Self Check

Write two Python functions to find the minimum number in a list. The first function should compare each number to every other number on the list. \(O(n^2)\). The second function should be linear \(O(n)\).
